79G Millimeter Wave Level Detection Sensor HLK-LD8001 Module Non-Contact High Precision Ranging B

79G Millimeter Wave Level Detection Sensor HLK-LD8001 Module Non-Contact High Precision Ranging B Περιγραφή

LD8001 is a sensing module developed based ADT3102 chip, with monolithic integration of 76-81GHz RF transceiver system, 1T1R PCB high gain antenna, 1MB flash, signal processing unit, ARM Cortex -M3 core.
This module is based FMCW signal processing mechanism, combined with signal processing algorithms, to realize high-precision ranging, suitable for high-precision liquid level and material level measurement.

Detection Based FMCW FM Continuous Wave Signal
Measuring distance to 15m
Highly accurate continuous measurement with an error of +/-5mm
Antenna -3dB Angle 100 Horizontal, 80 Tilt
Support SPI, Uart, I2C standard communication interface
Compact size, R=19.5mm, pin header connection
Flexibility to add lenses to change the antenna angle
Unaffected by temperature, humidity, noise, airflow, dust, light and other environmental influences
Application Scenarios:Industrial level measurement,Sewer level detection,Non-contact measurement of medical acidic and alkaline liquids,Fuel tanks, IBC tonne drums, viscous liquid measurement
specification:B
Colour:As Shown
Material:PC

Package Contents:
1 x HLK-LD8001 kit(Due to different product batches, the appearance may vary, which does not affect the use)

Only the above package content, other products are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
