Circuit Breaker Protector Cover40A Dual Battery

Circuit Breaker Protector Cover40A Dual Battery Beschreibung

Tripping characteristics: 1. Test ambient temperature: 253 2. Rated current200%: tripping within2-28s'' 3. 150% of rated current: trip within hour4. Rated current: keep without tripping5. Auto Reset - Resets automatically, but continues to trip (cycle on and off) until the fault is corrected. Specification1. Product name: AR series current overload protector (circuit breaker) 2. Rated current: 40A3. Input voltage: 125VAC/250VAC50VDC50-60HZ4. Electric strength: 1500VAC/1min, leakage current: 0.5mA5. Insulation resistance: 500VDC1Min100MΩ 6. Rated short-circuit capacity: 125VAC/1000A, 250VAC/1000A7. Rated on-off capacity: 6times rated current8. Reset method: automatic reset9. Reset time: reply within60S'' 10. Thread specification: #10-32 11. Scope of application: automobiles, cruise ships, RVs, modified cars, power tools, energy storage inverters, various generators, motors, UPS, electric heating appliances, etc... Packing list: 1*Overload protector Note: 1. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2. Please allow slight manual measurement deviation for the data.
