INSTRUMENTS R&D TC100 Coating Thickness Gauge 0.1µm/0-1300 Automotive Paint Description
This thickness gauge is used to measure the thickness of electroplated coatings on metal surfaces. It measures, in particular, the thickness of non-magnetic coatings (e.g., chrome, paint, ceramic, etc.) on magnetic materials such as steel and iron, as well as the thickness of coatings (e.g., paint, etc.) on non-magnetic materials such as copper and aluminum. The device features an integrated precision probe that automatically determines the substrate properties and the coating thickness through electromagnetic induction and eddy currents. Application: This device measures the thickness of coatings and plating layers quickly and precisely, without damage. It is frequently used in manufacturing, metal processing, the chemical industry, raw material testing, and other testing fields. It is an indispensable tool for the surface treatment of materials. It can operate reliably in laboratories, workshops, and outdoors.
Full-screen LCD large-screen display
Integrated F&NF probe, can automatically measure iron-based surface coatings and non-magnetic surface coatings such as aluminum.
Both sides of the housing are robustly constructed
Measuring range: 0-1300 µm
Measuring accuracy: (3% + 2 µm)
Minimum resolution: 0.1 µm
Equipped with 6 reference points, 0/50/100/250/500/1000 µm, very convenient to set, with automatic shut-off function, automatically shuts off after 15 minutes of inactivity to save power
Power supply: 1 x 9V battery (without)
Operating ambient temperature: 0C to 40C (32F to 104F)
Color: As shown
Material: ABS
Package includes:
1 set x TC-100 coating thickness gauge
Only the above package contents, other products are not included.
Note: Light reflections and different displays may cause the color of the item in the picture to differ slightly from the actual product. The allowable measurement error is +/- 1-3 cm.
