24bit 192khz DAC Digital Audio Decoder Optical Fiber Coaxial Digital Signal Input Stereo Output Decod Board

24bit 192khz DAC Digital Audio Decoder Optical Fiber Coaxial Digital Signal Input Stereo Output Decod Board Description

Feature: Sampling frequency range from 32KHZ to 192KHZ 24bit D/A converter Output 105DB dynamic range -90DB total harmonic distortion + signal to noise ratio Compatible with IEC60958, S/PDIF, EIAJ CP1201, AES3 protocol Linear filter output 5V working voltage 5V 3.3V Minimum Typical Maximum Minimum Typical Maximum Dynamic Range 18 to 24 bit A-weighted 99 105 97 103 dB unweighted 96 102 91 100 dB 16bit A-weighted 90 96 90 96 dB unweighted 87 93 87 93 dB Total harmonic distortion +noise 18 to 24 bit 0dB -90 -85 -90 -85 dB -20dB -82 -76 -80 -74 dB -60dB -42 -36 -40 -34 dB 16bit 0dB -90 -84 -90 -84 dB -20dB -73 -67 -73 -67 dB -60dB -33 -27 -33 -27 dB Dynamic Range 18 to 24 bit A-weighted 95 105 93 103 dB unweighted 92 102 90 100 dB 16bit A-weighted 86 96 86 96 dB unweighted 83 93 83 93 dB Total hannonic distortion +noise 18 to 24 bit 0dB -90 -82 -90 -82 dB -20dB -82 -72 -80 -70 dB -60dB -42 -32 -40 -30 dB 16bit 0dB -90 -82 -90 -82 dB -20dB -73 -63 -73 -63 dB -60dB -33 -23 -33 -23 dB Package includes: 1 x Digital Audio Decoder
