3X WBR3 Module Low Serial WiFi/ 4.2 MCU Module Socket Cloud Module 16x24mm

3X WBR3 Module Low Serial WiFi/ 4.2 MCU Module Socket Cloud Module 16x24mm Description

Embedded low-power 32-bit CPU, which can also function as an application processor
Clock rate:120 MHz
Working voltage:3.0V to 3.6V
Peripherals: 9 GPIOs, 1 UART, and 1 ADC

Wi-Fi connectivity
- 802.11b/g/n
- Channels 1 to 14 at 2.4 GHZ
- Support WEP, WPA/WPA2, WPA/WPA2 PSK (AES),WPA3 security modes
- to +16 dBm output power in 802.11b mode
- EZ net pairing mode for Android and iOs devices
- Onboard PCB antenna with a gain of 1.5 dBi
- Working temperature: -40 to +85
LE
- Support LE (V4.2)
- Maximum output power + 6dBm
Applications:
Intelligent building
household and home appliances
socket and light
Industrial wireless control
Baby monitor
Network camera
Intelligent bus
Color:As Shown
Material:PCB

Package Contents:
3 x WBR3 Module
