-7801A, Temperature and Humidity Incubator Controller

-7801A, Temperature and Humidity Incubator Controller Description

-7801A, Temperature and Humidity Incubator Controller Description
Supply voltage: AC 100-240 V, 50/60 Hz. Output load: R1 load 5 A/250 Vac, R2, R3 load 16 A/250 Vac, R4, R5 load 3 A/250 Vac (all loads are resistive). Setting range: Humidity 5%-95%, relative humidity value 0.1%; Temperature: -20C-60C, increments 0.1C. Measurement accuracy: Temperature 1%, Humidity 5%. Operating environment: -20C-45C. No condensation at 10-90F.
Product Introduction:
-7801A is an intelligent, miniaturized temperature and humidity controller with IP65 protection. It is characterized by its small size, light weight, ease of use, and convenient installation.
Main functions:
Cooling control
Heating control
Dehumidification control
Humidification control
Dew warning
Alarm output
Time-controlled load output
Load delay output
Overall dimensions: Length 78 x Width 34.5 x Depth 71 (mm)
Opening size: Length 71 x Width 29 (mm)
Protection class: IP65 (front panel)
Note: Due to different factory batches, product names may vary, and the color and appearance of the product accessories may differ slightly, but this does not affect normal use.
Color: as shown Pictured
Material: PC + ABS
Package Contents:
1 * -7801A Temperature and Humidity Controller
1 * -SHR05A Sensor
Only the above package contents, other products are not included.
Note: Light reflections and different displays may cause the color of the item in the picture to be slightly different from the actual product. The allowable measurement error is +/- 1-3 cm.
