ATOMS3R CAM Camera Development Board ESP32-S3 Programmable Controller

ATOMS3R CAM Camera Development Board ESP32-S3 Programmable Controller Description

ATOMS3R CAM Camera Development Board ESP32-S3 Programmable Controller Description
The Atoms3R Cam is a programmable mini-controller with an integrated camera. It features the ESP32-S3-1-N8R8 main controller with integrated Wi-Fi, 8 MB of flash memory, and 8 MB of PSRAM. It includes a power management circuit that converts 5 V to 3.3 V, as well as three integrated BMM150 geomagnetic sensors and six BMI270 orientation sensors.
Additionally, the product is equipped with a 0.3 MP GC0308 camera that supports image capture and infrared transmission control. Compared to previous products, the Atoms3R Cam's 3D antenna has been improved, offering enhanced performance and greater stability. The product ships with pre-installed UVC (USB Video Class) firmware, allowing it to function as a driverless USB camera. Users can use the camera directly via the USB interface without needing to install any drivers. The product also features a Type-C interface for power and firmware updates, as well as an HY2.0-4P expansion port. Six GPIO and power pins are reserved on the underside for easy expansion. Thanks to its compact size, it is suitable for embedded scenarios such as monitoring IoT devices and as a development tool for the education sector.
Integrated ESP32-S3-1-N8R8 main controller
300,000-pixel camera GC0308
Nine-sensor system (six BMI270 + three BMM150 geomagnetic sensors)
8 MB Flash and 8 MB PSRAM
Supports infrared control
Expandable pins and interfaces
Development platforms: for , for UIFlow, for Micropython
Applications:
Driverless USB camera
Motion detection and direction measurement
Portable Device
Control of intelligent devices
IoT applications
Note: Due to different production batches, there are differences in printing/appearance, which do not affect use.
Color: As pictured
Material: Plastic + components
Package contents:
1 * ATOMS3R camera
Only the above package contents, other products are not included.
Note: Light reflections and different displays may cause the color of the item in the picture to be slightly different from the actual product. The allowable measurement error is +/- 1-3 cm.
