Cabin height control valve for cabin air suspension system

Cabin height control valve for cabin air suspension system Description

Cabin height control valve for cabin air suspension system Description
Very important: Please check the product description and compatibility before purchasing.
Made of high-strength EGP (Engineering Grade Polymer), guaranteeing durability and resistance.
One valve can be used for left and right mounting. One valve can control two air springs.
Air connection: 1/4 inch NPT. Supply Port: 1/4" NPT
Replacement for the Hadley H00600P Low Flow Leveling Valve.
Part Number: for Hadley H00600P
Part: Low Flow Leveling Valve (Hadley Type)
Air Port: 1/4" NPT
Drain Valve Included: No
Outlet Port Diameter: 1/4" NPT
Rod Adjustment: Horizontal / Vertical
Rod Lengths: 8 1/2" / 9 1/2"
Series: Immediate Response (IR)
Supply Port: 1/4" NPT
Notes: Used to maintain vehicle height on air-sprung chassis
Application: Air Suspension System for Driver's cabs
Cross reference:
for Automann: 171.H00600POE
for: E11464
for Hadley: H00600P
for: KN27201
for: 20QE2373
for Meritor: R3011464
for Navistar: 3595979C91, 3595979C92, 2040945C91
for PAI: 740225
Color: As shown
Material: Metal
Package contents:
1 set * Height adjustment valve
Only the above mentioned Package contents, other products are not included.
Note: Light reflections and different displays may cause the color of the item in the picture to be slightly different from the actual color. The allowable measurement error is +/- 1-3 cm.
