ESP32 S3 1.8-inch AMOLED touchscreen display development board

ESP32 S3 1.8-inch AMOLED touchscreen display development board Description

ESP32 S3 1.8-inch AMOLED Touchscreen Display Development Board Description
Supports 2.4 GHz Wi-Fi (802.11 b/g) and Bluetooth 5 (LE), with integrated antenna
Built-in 512 KB and 384 KB ROM, 8 MB PSRAM and 16 MB external flash
Integrated 1.8-inch HD AMOLED touchscreen with 368 x 448 pixels and 16.7 million colors for clear color reproduction
Integrated SH8601 driver chip and FT3168 chip for capacitive touch, communicating via QSPI and I2C respectively, thus not occupying too many pin resources
Integrated QMI8658 unit with six Inertial measurement functions (three accelerometers and three gyroscopes) for posture detection, step counting, and other functions. An integrated PCF85063 chip, connected to the battery via AXP2101, provides uninterruptible power and reserves a backup battery pad to ensure continued functionality even after the main battery is replaced. Two customizable side buttons for PWR and BOOT on the board allow for the development of custom button functions. Seven GPIO, one I2C, one UART, and one USB pad are brought out for external devices and debugging, and peripheral functions can be flexibly configured. The integrated microSD card slot provides expanded storage and fast data transfer. Data transmission and flexibility, suitable for data recording and media playback, and simplifies circuit design.
Color: Black
Material: Plastic
Package Contents:
1 x 1.8-inch AMOLED Display
Only the above package contents, other products are not included.
Note: Light reflections and different displays may cause the color of the item shown to differ slightly from the actual product. The allowable measurement error is +/- 1-3 cm.
