HMC219 Passive Double Balanced Mixer HMC219 Passive Double Balanced Mixer Module

HMC219 Passive Double Balanced Mixer HMC219 Passive Double Balanced Mixer Module Description

HMC219 Passive Double Balanced Mixer HMC219 Passive Double Balanced Mixer Module Description
The HMC219 is a high-performance passive double-balanced mixer. Utilizing GaAs Schottky diodes and an innovative planar transformer balun structure, it offers a wide operating frequency range and stable performance. It is suitable for a variety of applications, including upconversion, downconversion, bi-phase modulation/demodulation, and phase comparison.
Feature
Frequency Range:
/LO: 2.5 GHz to 7 GHz
IF: DC to 3 GHz
Low Mixing Loss: Only 9 dB
High Isolation:
LO/ Isolation: 40 dB
LO/IF Isolation: 35 dB
Low Noise Figure (): 8 dB
High Linearity (P1dB): 11 dBm
LO Drive Power: 13 dBm
Passive Design, No External Bias Required
Model: HMC219
Operating Temperature: -40C to +85C
Applications:
Microwave Communication Systems
Radar and Satellite Communications
Test and Measurement Equipment
Wireless Infrastructure (5G/4G Base Stations)
Modemization, Demodulation, and Phase Detection Circuits
Advantages Compared to Similar Models: Compared to the HMC175 and HMC213, the HMC219 offers a operating frequency (up to 7 GHz), higher isolation (LO/ 40 dB), and lower mixing loss (9 dB), making it ideal for high-frequency, high-linearity applications.
Color: Green
Material: PCB+Metal
Package Contents:
1*HMC219 Passive Double-Balanced Mixer
Only the above package content, other products are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
