Summary
- Lens focal length of 4mm for enhanced image clarity
- Wide field of view of 42° x 32.1° for better situational awareness
- Detection distance up to 400m and recognition distance of 100m for effective monitoring
- Adjustable image enhancement modes including brightness and contrast for optimal visibility
- Compact dimensions of 21mm x 21mm x 29.8mm for easy integration into various systems
Infrared Thermal Imaging Module High-Definition Camera CVBS Interface 256X192 4MM for Drone Thermal Imager Description
Lens length of 4mm for enhanced image clarity
Wide field of view of 42 x 32.1 for better situational awareness
Detection distance to 400m and recognition distance of 100m for effective monitoring
Adjustable image enhancement modes including brightness and contrast for optimal visibility
Compact dimensions of 21mm x 21mm x 29.8mm for easy integration into various systems
Lens length: 4mm
Field of view (): 42*32.1
Detection distance: 400m
Recognition distance: 100m
Resolution distance: 50m
Spectral response: 8~14um
Pixel count: 12um
Array size: 256*192 (effective area array)
NETD 25mK (f/1.0 50Hz 300K)
Detector frame rate: 50Hz
Analog image interface: CVBS
Control interface UAR (Baud Rate: 115200)
Interface Specifications: SMD, P=1.25mm-5P
Electronic Zoom: 1X~8X zoom
Baffle Mode: With baffle, automatic baffle adjustment
Calibration: Supports UART serial protocol
Non-uniformity correction (NUC): Supports UART serial protocol
Power Input: 4.5V~18V
Operating Temperature: -20C~+60C
Power Consumption: 0.8W
Color: Black
Material: plastic
Package Contents:
1*Thermal Imager
Details
| OPC | PSWG9HD |
|---|---|
| Brand | Saudism |
| Codes | 6032760142144 (EAN) |
| Product and Safety Information |
Product Data
| Height | 5cm |
|---|---|
| Width | 9cm |
| Length | 10cm |
| Weight | 0.0615kg |
| Colour | Black |
| Material | plastic |
