SEG?10?2 Dial Tensiometer Portable Double Pointer Tension Gauge Force Meter Tools 10g

SEG?10?2 Dial Tensiometer Portable Double Pointer Tension Gauge Force Meter Tools 10g Description

Feature:
1. SEG?10?2 gauge tension meter, measuring value is 10g, high accuracy.
2. Using high?quality alloy materials, strong and durable, corrosion?resistant.
3. Fine craftsmanship forging makes the measurement more accurate and faster.
4. Support one?handed operation, streamlined body, compact and portable.
5. Suitable for relay contact pressure, electronic switch, micro switch, valve, spring tension, etc.
Specification:
Item Type: Tension Gauge
Material: ABS+Alloy
Model Specification: SEG-10-2
Pointer: Double Pointer
Measurement Value: 10g
Graduation Value: 0.2g
Scale Style: 2-10-2
Accuracy: ??0.5
Product Use: Tensiometer (g) is suitable for mechanical pressure such as relay contact pressure, electronic switch, micro switch, valve, spring tension, dial measuring instrument spindle pressure, automatic telephone equipment contact and armature pressure, tape recorder buffer device pressure and other contact point pressure, and other precise pressure and tensile tests.
How to Use:
When testing, just use the stylus to move the object to be tested to move it from the static state to the required position. The tensiometer can be tested either clockwise or counterclockwise, but the stylus arm must always be perpendicular to the direction of the push-pull force; tension scoring is divided into single and double pointers. The single-pointer tensiometer measures and reads immediately. After the double-pointer tensiometer measures the highest value, follow-up pointer stops moving, which is convenient for the tester to read the test value..
Package List:
1 x Dial Tension Gauge
Note:
1. Do not drop the product randomly.2. Do not bend the measuring alloy probe.3. When the product cannot be calibrated, you can open the back cover for calibration. It is not recommended to open the back cover for calibration frequently.
