Universal Electronic Eyepiece for Microscopes, 2 MP, Digital USB Microscope Camera, Imager for Science Education in Schools

Universal Electronic Eyepiece for Microscopes, 2 MP, Digital USB Microscope Camera, Imager for Science Education in Schools Description

Universal Electronic Eyepiece for Microscopes, 2 MP, Digital USB Microscope Camera, Imager for Science Education Description
1. TWO OPERATING MODES: Eyepiece supports manual or automatic white balance, manual or automatic exposure, stainless steel metal housing.
2. SENSITIVE AND PRECISE: Electronic eyepiece with 1/3-inch sensor, progressive scan, low light intensity and high sensitivity.
3. CLEAR IMAGES: The eyepiece uses 960 TV cable hardware and a professional micro image sensor, ensuring clear images and good color reduction. The factory setting is PAL.
4. PERFECT REPLACEMENT: Used to replace the eyepiece on conventional microscopes and to convert existing conventional microscopes with 23 mm or 30 mm eyepiece diameter into digital microscopes
5. MANY FUNCTIONS: More powerful eyepiece with new functions such as measuring, calibrating, recording, and comparing.
Item Type: Electronic Eyepiece
Microscope Connection Mode: Approx. 23.2 mm/0.91 in diameter interface, inserted directly into the eyepiece tube.
Output: Video, CVBS
Digital Image: None
Image Sensor Size: 1/3 in, approx. 4.840 x 3.611 mm/0.19 x 0.14 in
Horizontal Sensor Resolution: 960 TV Cable
Effective Sensor Pixels: PAL: 968 (H) x 488 (V), NTSC: 960 (H) x 480 (V)
Image Control: Manual or automatic white balance, manual or automatic Exposure
Minimum illumination: 0.005
Signal-to-noise ratio: 43.6 dB
Dynamic range: 65.9 dB
Operating voltage: 12 V (Operating current: 90 mA)
Power consumption: 140 mW
Operating temperature: -20 to 50 C
Relative humidity: less than 90%
Color: Black
Material: ABS
Package contents:
1 * Electronic eyepiece
