ESP32 S3 Development Board 2.41inch AMOLED Touch Display 600x450

ESP32 S3 Development Board 2.41inch AMOLED Touch Display 600x450 Beschrijving

ESP32 S3 Development Board 2.41inch AMOLED Touch Display 600x450 Description
1. The product uses the ESP32-S3R8 chip, supports 2.4GHz Wi-Fi and BLE 5 Bluetooth functions, and has built-in large-capacity Flash and PSRAM
2. Equipped with a 2.41-inch high-definition AMOLED display, it can run GUI programs such as LVGL smoothly
3. Onboard RTC, IMU, Micro-SD card slot and lithium battery charging function, rich peripheral resources, and reserved USB, UART, I2C and 34PIN GPIO interfaces, providing flexible expansion capabilities, and is an ideal choice for rapid development of HMI applications based on ESP32-S3
4. Built-in 512KB SRAM and 384KB ROM, stacked 16MB Flash and 8MB PSRAM
5. Onboard QMI8658 six-axis inertial measurement unit (3-axis acceleration, 3-axis gyroscope), which can detect motion posture, step counting, etc.
Onboard PCF85063 RTC chip, reserved SH1.0 battery slot (supports charging) to facilitate RTC function requirements.
Onboard RST, BOOT and PWR side buttons, BOOT and PWR also support custom button functions, more flexible development and use.
Onboard Micro-SD card slot, can be connected to an external Micro-SD card to store pictures or files.
Onboard USB Type-C interface, can be used for power supply and download debugging, convenient for development and use.
Lead out UART and I2C SH1.0 4PIN interface, and reserve 34PIN 2.54mm spacing GPIO interface for easy expansion and development.
Display panel: AMOLED
Display resolution: 600 x 450
Communication interface: QSPI
Display size: 2.41inch
Display color: 16.7M
Contrast ratio: 100000:1
Driver IC: RM690B0
Touch IC: FT6336
The product appearance and printed words may vary depending on the batch, but this does not affect use.
Colour:Black
Material:ABS+LCD
Package Contents:
1 * LCD Display
Only the above package content, other products are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
