For DeepSeek Xiaozhi AI Voice Chat Robot ESP32-S3 Development Board

For DeepSeek Xiaozhi AI Voice Chat Robot ESP32-S3 Development Board Beschrijving

For DeepSeek Xiaozhi AI Voice Chat Robot ESP32-S3 Development Board Description
Support for AI acceleration: ESP32-S3 MCU adds vector instructions for accelerating neural network calculations and signal processing. AI developers can use these vector instructions through the ESP-DSP and ESP-NN libraries to achieve high-performance image recognition, voice wake-up and recognition applications. ESP-WHO and ESP-Skainet will also support this feature
Complete security mechanism: ESP32-S3 provides a complete security mechanism and protection measures for IoT devices to prevent various malicious attacks and threats. It supports flash encryption based on the AES-XTS algorithm, secure boot based on the RSA algorithm, digital signatures and HMAC. ESP32-S3 also adds a new "World Controller" module, which provides two non-interfering execution environments to implement a trusted execution environment or a privilege separation mechanism
Wi-Fi + Bluetooth 5 (LE): ESP32-S3 integrates 2.4 GHz Wi-Fi (802.11 b/g/n) and supports 40 MHz bandwidth; its low-power Bluetooth subsystem supports Bluetooth 5 (LE) and Bluetooth Mesh, and can achieve long-distance communication through Coded PHY and broadcast extension. It also supports 2 Mbps PHY to increase transmission speed and data throughput. ESP32-S3's Wi-Fi and Bluetooth LE radio performance are excellent and can work stably even at high temperatures
Rich IO interfaces: ESP32-S3 has 45 programmable GPIOs and commonly used peripheral interfaces such as SPI, I2S, I2C, PWM, RMT, ADC, UART, SD/MMC host controller and TwAITM controller. 14 of the GPIOs can be configured as capacitive touch inputs for HMI interaction. In addition, ESP32-S3 is equipped with an ultra-low power coprocessor (ULP), which supports multiple low-power modes and is widely applicable to various low-power application scenarios
Mature software support: ESP32-S3 uses Espressif's mature IoT development framework ESP-IDF. ESP-IDF has successfully enabled hundreds of millions of IoT devices, has undergone rigorous testing and release cycles, and has a clear and effective support strategy. Based on its mature software architecture, developers will find it easier to build applications or migrate existing programs to the ESP32-S3 platform with their familiarity with tools and APIs
Battery: 300mah lithium battery
Speaker: 8 ohm 1W
N16R8 (16M external flash/8M PSRAM)/AI I0T/dual Type-C USB ports/W2812 rgb/high-speed USB to serial port
Colour:Random, don't accept the specified color
Material:plastic
Package Contents:
1 * AI Voice Chat Robot
Only the above package content, other products are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
