Step-Down Solar Controller for 12V 24V Lithium Lead-Acid Gel Battery

Step-Down Solar Controller for 12V 24V Lithium Lead-Acid Gel Battery Beschrijving

Step-Down Solar Controller for 12V 24V Lithium Lead-Acid Gel Battery Description
Note:Due to different printing batches, if there are slight differences in the words in kind, it not affect the use.
Working voltage: 18-80V; Maximum current: 20A
Rated power: 12V20A/240W, 24V20A/500W
Compatible batteries: lead-acid/lithium battery/colloid battery, etc.
Heat dissipation: natural cooling + smart fan
Product name:MPPT solar buck controller
Display: LED digital tube display
Conversion efficiency: 98%
Rechargeable voltage:12V 24V
Working temperature:-20-60
Protection level:IP30
Precautions:
1. It is strictly forbidden to use the controller with overvoltage and overpower. The controller not work if it is only connected to the battery without connecting the solar panel
2. Before installing the controller, please determine the voltage level, which must be consistent with the battery voltage. It is strictly forbidden to charge the low-level battery with a high-level voltage
3. Installation steps: first connect the solar panel to the controller, and then connect the battery. The input and output of the controller are both red positive and black negative
4. The length of the wire connecting the controller should be as short as possible to reduce power loss
5. The solar panel should be placed in a place without any obstruction from the sun
6. The controller heat up during operation, and it is recommended to install it in a ventilated and heat-dissipating environment
7. The blue (black) line in the charging line of the-original electric vehicle charger is the positive pole, and it should be connected to the of the controller output line.
Color:Silver Grey
Material:Metal
Package Contents:
1 * solar controller
Only the above package content, other products are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
