Truck Air Standard Leveling Height Control Valve Kit Replace VS-227

Truck Air Standard Leveling Height Control Valve Kit Replace VS-227 Beschrijving

Truck Air Standard Leveling Height Control Valve Kit Replace VS-227 Description
Used on most of American Truck/Trailer.
Replaces: VS227, 171.H184, 53321-Q120, 90054007, KD2204, 50433001, 60826000, E11494, HTSVS227
Fitment: For All Hendrickson Suspension Applications, All 1980 's Through Current Neway Trailer Air Suspensions, Most Other Trailer Air Suspensions.
Installation Recommend: When Not Exceeding The Maximum Movement Angle of 45 degrees, The Length Ratio L / A Should Be less than equal 1.2. The Length L Should Be Between 175 and 295 mm. If A Shorter Yaw is Used, The Height Valve Generate A Large Air Consumption.
Product Name: Air Height Leveling Valve
Type: Truck Leveling Valve
Inlet Port: NPT1/4
Max Working Pressure: 1.2Mpa
Mounting Hole Centre: 38mm
Mounting Thread: 1/4-20UNC
Manufacturer Part Number: 50433001,VS-227
Other Part Number: 50433001, 60826000, E11494, HTSVS227
Interchange Part Number: 53321-Q120,90054007, KD2204
colour:As shown
Material:aluminum
Package Contents:
1 x Air Height Leveling Valve
Only the above package content, other products are not included.
Note: Light and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
