Digital Flow Meter with Display for Gear Systems, 0.1-7 L/Min, Accurate Liquid Measurement for Industrial Use

Descrição de Digital Flow Meter with Display for Gear Systems, 0.1-7 L/Min, Accurate Liquid Measurement for Industrial Use

Model: K24

Compatible media: methanol, diesel fuel, kerosene, chemical liquids, urea, and water. Designed for a wide range of liquid transfer and monitoring applications, it supports stable use with common industrial and household fluids.

Inlet size: 1-inch internal thread. Measurement accuracy: 1%. Repeatability: 0.5%. Maximum working pressure: 5 BAR. Operating voltage: 2.3-3.3 V.

Single count range: 0.00-9999.9. Total cumulative count range: 0.00-999999.9. Supported units: L, GAL, PTS, and QTS. Single measurement reset function: RESET.

Unit setting procedure: in standby mode or the current display state, press CAL + RESET for 5 seconds to enter the unit conversion settings. Press RESET to cycle through the units in the following order: LTR GAL PT QT LTR. The cumulative volume updates in the selected unit. Press MENU for 3 seconds to exit.

Flow range: 0.1-7 L/min. Color: blue and black. Material: PPS and stainless steel. Package contents: 1 x flow meter. Note: requires 2 AAA batteries, batteries not included. The low battery indicator, LBat, appears when the voltage is between 2.2 V and 2.4 V. Color may vary slightly due to lighting and screen differences. Measurement tolerance: 1-3 cm.
