X1008 PCIe to 2.5 Inch HDD / SSD + 3.5 Inch HDD Shield for Raspberry Pi 5

Samenvatting

• X1008 PCIe to 2 ports SATA HDD expansion board, designed to provide a mass-capacity storage and high-speed storage solution for your Raspberry Pi 5. This board facilitates the simultaneous connection of a 3.5-inch HDD and a 2.5-inch HDD/SSD, unleashing the full potential of your storage capabilities, with SATA 3.0 interface speeds reaching up to 5Gbps.
• With support for 12V input via a standard DC jack and equipped with high-efficiency DC/DC step-down converters, the X1008 efficiently powers both your Raspberry Pi5 and HDDs from a single power source, simplifying your setup.
• The X1008 serves as the perfect storage solution for establishing a home media center or constructing a network-attached storage (NAS) system. It empowers you to store and stream your personal collection of videos, music, and digital photos within the confines of your home or remotely from anywhere around the globe. Important Notes: The X1008 is designed for data storage purposes and does not currently support booting from HDD/SSD with the existing firmware.
• Don't power the X1008 and the Raspberry Pi5 at the same time. Older SATA drives with less efficient flash media may not perform as well as newer drives. New SATA HDDs/SSDs are not partitioned and will need to be both partitioned and formatted when first connected to the Raspberry Pi before they will be accessed in the Explorer. Compatible With for Raspberry Pi 5B. Supports the connection of a 3.5-inch SATA HDD and a 2.5-inch HDD/SSD to your Raspberry Pi 5 simultaneously
• Compliant with the Serial ATA 3.0 specification, with backward compatibility to SATA 2.0 and SATA 1.0. Adheres to the PCI-Express v2.0 specification and is backward compatible with PCI-Express v1.0. Supports communication speeds of 5.0 Gbit/s, 3.0 Gbit/s, and 1.5 Gbit/s. Compatible with SATA 6G, 3G, and 1.5G hard drives. Features plug-and-play installation for ease of setup. LED indicators display power and drive status
