2X Industrial Control STM32F407VET6 Development Board RS485 Dual CAN Ethernet Networking STM32
Ny
På lager
Derfor vil du elske at handle hos OnBuy:
- Tjen Cashback på hvert køb – brug det med det samme på din næste ordre
- Gratis levering – på millioner af varer på siden
- Kunder elsker os – 134,000 anmeldelser med vurderingen “Fremragende”
513,49 kr.
847,26 kr.
Spar 39%!
+41,20 kr. levering
1%
Tjen 5,13 kr. med det samme
Læs mere
Priserne for varer, der sælges af OnBuy, inkluderer moms.
Rentefrie betalingsmuligheder
Se fuld produktbeskrivelse og detaljer
Levering: Standard (41,20 kr.) | man. 28. sep. - lør. 3. okt.
Solgt af: Hoeappt
Returnering: 30 dage
180 dages betalingsbeskyttelse
Du kan også lide
Beskrivelse og detaljer
Oversigt
- Master MCU:STM32F407VET6-LQFP100
- Ethernet chip:DP83848-LQFP48
- Serial port:1 RS232 interface with serial port 1 PA9 PA10
- RS485 interface:1 RS485 interface with serial port 2 PD5 PD6
- CAN interface:2 CAN interfaces with chip PD0 PD1 / PB5 PB6
2X Industrial Control STM32F407VET6 Development Board RS485 Dual CAN Ethernet Networking STM32 Beskrivelse
Master MCU:STM32F407VET6-LQFP100
Ethernet chip:DP83848-LQFP48
Serial port:1 RS232 interface with serial port 1 PA9 PA10
RS485 interface:1 RS485 interface with serial port 2 PD5 PD6
CAN interface:2 CAN interfaces with chip PD0 PD1 / PB5 PB6
The development board uses the STM32F407VET6 chip as the main controller, M4 super core, expansion with 1 RS232 interface, 1 RS485 interface, 2 CAN interfaces, 1 Ethernet interface, 1 USB HOST interface, 1 USB DEVICE interface , Three user buttons, three user indicators. Very suitable for loT application development, gateway server development, bus communication development and industrial control.
TF card:9-pin small card, controlled by thePC and PD pins
Wireless interface:P3 leads to NRF24L01 interface
USB interface:One master USB and one slave USB
Storage:Built-in 24C02 and 25Q64 memory chips
Temperature Sensor interface:Lead out DS18B20 sensor interface
JTAG interface:JTAG corresponding to J-LINK
button:K1,, K3 three user buttons
Indicator light:LED1,LED2, LED3 three user indicators
Note:Due to different product batches, the appearance may be different, which does not affect use.
Colour:
Material:PC+Metal
Package Contents:
2 x Development Board
2 x Cable
Detaljer
| OPC | PXY6GP8 |
|---|---|
| Koder | 6031132501411 (EAN) |
| Produkt- og sikkerhedsoplysninger |
Produktdata
| Height | 4cm |
|---|---|
| Width | 10cm |
| Length | 18cm |
| Weight | 0.239kg |
| Colour | Blue |
| Material | PC+Metal |
