Beskrivelse og detaljer
Oversigt
- The XL-10AH is wide voltage versions. This modules can achieve the same function as self-locking switches by lightly touching the switch to turn on and off the power.
- It can support a load with a maximum switch current of 10A, can support a wide range voltage of 4.5-26V, and the static power consumption in the off state is about 1.3ua.
- The excellent performance of the module covers the working voltage and operation required for most DC loads. The small size design also does not take up too much space on your device.
- For the button part, if you want to use other styles of buttons, you can also connect various other styles of touch buttons to our switch control board through wires.
- Bistable Switch Module
3Pcs Single Bond Button Bistable Module 4.5-26V 1.3UA Load 10A Low Power Wide Voltage One Key Module Beskrivelse
The XL-10AH is wide voltage versions. This modules can achieve the same function as self-locking switches by lightly touching the to turn and off the power.
It can support a load with a maximum current of 10A, can support a wide range voltage of 4.5-26V, and the static power consumption in the off state is about 1.3ua.
The excellent performance of the module covers the working voltage and operation required for most loads. The small size design also does not take too much space your device.
For the button part, if you want to use other styles of buttons, you can also connect various other styles of touch buttons to our control board through wires.
Model: XL-10AH
Working voltage: 4.5-26V
Static power consumption: 1.3ua (12V voltage measurement)
Load current: 10A (12V voltage test for 30 minutes)
Pressure drop: 120mv (12V 10A measurement)
Colour:Black
Material:PCB
Package Contents:
3 x XL-10AH Module
Detaljer
| OPC | PSRG9CT |
|---|---|
| Mærke | Semoic |
| Koder | 6032862362563 (EAN) |
Produktdata
| Height | 3cm |
|---|---|
| Width | 1cm |
| Length | 3cm |
| Weight | 0.0075kg |
| Colour | Black |
| Material | PCB |
