For M5Stack Tab5 IoT Controller/Development Kit Portable IoT Terminal ESP32-P4 + ESP32-C6 with NP-F550 Battery
New
1.127,30 kr.
Lignende produkter, vi tror du vil kunne lide
Would you like us to let you know when it's back?
Beskrivelse og detaljer
Oversigt
- Tab5 is a developer-oriented, highly extensible portable IoT terminal development device. Its main controller is the RISC-V-based ESP32-P4 SoC, equipped with 16 MB Flash and 32 MB PSRAM; the wireless module uses ESP32-C6-MINI-1U, supporting Wi-Fi 6 with an antenna system that can switch between a built-in 3D antenna and an external MMCX antenna port.
- Tab5 features a 5Inch 1280x720 IPS TFT display driven over MIPI-DSI, with touch input handled by the GT911 multi-touch controller (I²C) for smooth, precise response. A MIPI-CSI-connected SC2356 2 MP camera (1600x1200) enables HD video capture, image processing, and edge AI applications (e.g., face recognition, object tracking).
- I/O and expansion include USB-A (Host) and USB-C (USB 2.0 OTG) ports for traditional peripherals; industrial communication via RS-485 (SIT3088 with switchable 120 Ω termination); 1 x GROVE, 1 x M5BUS, GPIO_EXT header, and a Micro-SD slot; plus a STAMP solder-pad for Cat.M/NB-IoT/LoRaWAN modules. A Reset/Boot button allows quick reset and firmware flashing.
- Tab5 is ideal for smart home control, remote monitoring, industrial automation, IoT prototyping, and educational research, offering developers and enterprises a full-featured, extensible, high-performance platform.
- Tab5 Kit
For M5Stack Tab5 IoT Controller/Development Kit Portable IoT Terminal ESP32-P4 + ESP32-C6 with NP-F550 Battery Beskrivelse
Tab5 is a developer-oriented, highly extensible portable IoT terminal development device. Its main controller is the RISC-V-based ESP32-P4 SoC, equipped with 16 MB Flash and 32 MB PSRAM; the wireless module uses ESP32-C6--1U, supporting Wi-Fi 6 with an antenna system that can between a built-in 3D antenna and an external MMCX antenna port.
Tab5 features a 5Inch 1280x720 IPS TFT display driven over MIPI-, with touch input handled by the GT911 multi-touch controller (I²C) for smooth, precise response. A MIPI-CSI-connected SC2356 2 MP camera (1600x1200) enables HD video capture, image processing, and AI applications (e.g., face recognition, object tracking).
I/O and expansion include USB-A (Host) and USB-C (USB 2.0 OTG) for traditional peripherals; industrial communication via -485 (SIT3088 with switchable 120 Ω termination); 1 x GROVE, 1 x M5BUS, GPIO_EXT header, and a Micro- slot; a STAMP solder-pad for Cat.M/NB-IoT/LoRaWAN modules. A Reset/Boot button allows quick reset and firmware flashing.
Tab5 is ideal for home control, remote monitoring, industrial automation, IoT prototyping, and educational research, offering developers and enterprises a full-featured, extensible, high-performance platform.
ESP32-P4 dual-core MCU
ESP32-C6 wireless module
Wi-Fi 6
Built-in 3D antenna & MMCX external antenna port
5Inch 720P MIPI- display
GT911 multi-touch
SC2356 2 MP camera
USB-A Host + USB-C OTG
-485 industrial interface
Grove & M5BUS expansion
Micro- card slot
STAMP expansion pad
ES8388 audio codec
ES7210 AEC dual microphones
1W speaker + 3.5 mm jack
BMI270 six-axis sensor
RX8130CE real- clock
Reset/Boot & Power buttons
NP-F550 2S removable battery
Standard 1/4Inch-20 tripod mount nut
Development platform
Detaljer
| OPC | PVNMVHK |
|---|---|
| Koder | 4711928023380 (EAN) |
| Produkt- og sikkerhedsoplysninger |
Produktdata
| Height | 2cm |
|---|---|
| Width | 10cm |
| Length | 20cm |
| Weight | 0.2825kg |
| Colour | White & Black |
| Material | Plastic |
