UHF 860-960MHz Impinj E710 4 Channels Long Range UHF RFID Reader Module Writer with SKD Develop Kit

UHF 860-960MHz Impinj E710 4 Channels Long Range UHF RFID Reader Module Writer with SKD Develop Kit Beskrivelse

TY902 is based the E710 chip design, Gen2 Extension Ready, maximizing chip potential with outstanding multi-tag anti-collision capability.
The 4-port high-throughput coordination design and advanced thermal balance planning ensure consistently high performance over .
All these make it ideal for meeting the high-performance RFID system requirements in fields such as warehousing, logistics, apparel, production lines, and retail. Additionally, sub-versions based the E510 and E310 are available.

Self-intellectual property;
Designed with IMPINJ E710 and support ISO18000-6C(EPC C1G2) protocol tag;
FHSS or Fix Frequency transmission with RF output to 33dbm (adjustable);
Effective distance to 20m (with external 12dbi antenna);
Maximum inventory speed over 1000pcs/s ;
Tag buffer size to 1000PCS @96bits EPC;
4 SMA antenna port with antenna failure detection;
Low power dissipation with single +3.8-5VDC power supply;
Support 4 GPIOs (2 input and 2 outputs);
Support RS232 (3.3V TTL level);
High reliability design;
Support -the-site firmware upgrading;
Support RSSI.
Colour:As Shown
Material:Aluminum alloy + PC
Due to different batches, there may be differences in product appearance and printed text, which will not affect use

Package Contents:
1 * UHF RFID Reader Module kit
