80A ESC WP-880 1/10 1/8 WP-Crawler Brush Brushed 80A 1080 Electronic Speed Controller Waterproof ESC with Program Card

80A ESC WP-880 1/10 1/8 WP-Crawler Brush Brushed 80A 1080 Electronic Speed Controller Waterproof ESC with Program Card Kuvaus

The product has the most basic resistance. Please do not throw it into water during use, as this may cause the product to burn down.Fine workmanship: fine workmanship, looks very beautiful.Easy to use,Easy to replace; 3 model( Forward/Brake/Reverse running mode) fits for various vehicles.
High efficiency design, light weight, reliable and very affordable.quality Water-proof and dust-proof,suitable for different Situations.Compact size, suitable for various car chassis.
Easy to set and easy to use the ESC parameters with jumpers and automatic throttle range calibration.Great current endurance capability and Great built-in BEC output capacity.
Small size with built-in capacitor module.Multiple protections: Low voltage cut-off protection for battery / Over-heat protection / Throttle signal loss protection.
Excellent operating feelings and plentiful adjustment options, suitable for most kinds of competitions.

Scale: 1 / 8 and 1 / 10
Wire drawing / brushless: Drawing
Waterproof: Yes
Crest value current / continuous: 80A / 400A
Input voltage: 2-3s lipid / 5-9 NIMH cells
BEC output: 5.8V/3A
Wires and connectors:
Input wire: red-16awg-200mm * 1 / black-16awg-200mm * 1
Output : -16awg-200mm * 1 / yellow-16awg-200mm * 1
Input connector: T-plug connector
(Fwd =Forward, Br=Brake, Rev=Reverse)
Fwd. Cont. / Current: 80A /400A
Rev. Cont. / Current: 30A /180A
Voltage Range: 2-3S Lipo or 5-9 NiMH
Cars Applicable: 1/10or1/8: Touring Car, Buggy, Short Course Truck, , Truggy, Rock Crawler and Tank
Motor Limit:
2S Lipo or 6 NiMH
540 / 550/570 Size Motor: 12T Or RPM Less than 30000 @7.2V
3S Lipo or 9 NiMH
540 or 550 Size Motor: 18T Or RPM Less than 20000 @7.2V
4S Lipo or 12 NiMH
Not Available
Resistance: Fwd 0.001Ω, R
