Module relais 16 canaux >200mA, 179x90x19mm, noir

New

26,58 €

Produits similaires que vous pourriez aimer selon nous

Circuit Board Semiconductors

Would you like us to let you know when it's back?

Ajouter au panier

Description et informations

Résumé

The relay contact capacity is 10A 250V, with optocoupler protection. The onboard power module does not require an external power supply, IO port drive active high
Can be used as a single chip development board module, as home appliance control, and also as a PLC expansion output
Using industry isolation optocoupler, possess strong anti interference ability and stable performance, trigger current only needs 3mA
1‑16 channels can be turned on or off arbitrarily, or any channels. The output can be directly connected to the load of AC 220V 10A or DC30V 10A
The common terminal COM of each relay is independent, which is convenient for users to access different signals. Each relay has a normally closed and normally open port

Description de Module relais 16 canaux >200mA, 179x90x19mm, noir

Module relais à 16 canaux avec protection par optocoupleur et alimentation, déclenchement par niveau haut
Type d'article : Module relais
Courant d'alimentation : Plus de 200 mA
Chaque sortie : 250 V 10 A (AC) ou 30 V 10 A (DC)
Taille du PCB : environ 179 90 19 mm / 7 3,5 0,7 pouces
