Brushless BLDC motor development board
Supports HALL signal access and reserved CAN and RS485 interfaces
Voltage: 12~36VDC
Rated current: 5A (8A with heat sink)
Support HALL signal access

Reserved CAN and RS485 interfaces for later upgrades and development
Use APM32F103RBT6 (software and hardware compatible with STM32F103RBT6) master control, vector control algorithm, non-ST motor library
Extraction code: 94e1
Supporting program source code:
1. Open-loop vector control: No need to connect hall signal, only need to connect motor dynamics U, V, W, can achieve 0~500rpm low-speed operation. (Disadvantage: The motor generates a lot of heat)
2. Speed closed-loop control: Need to connect hall signal, can achieve 120~3000rpm speed operation (the specific maximum operating speed depends the motor characteristics and power supply voltage), no open-loop control disadvantages, PID speed closed loop, automatically adjust the current according to the load size.
3. Position closed-loop control: Hall signal is required to achieve rough position control (positioning will have an error of 30~90 degrees), PID speed, position closed loop, and automatically adjust the current according to the load size.
Note: Suitable for people with certain development capabilities
Because it contains drawings and program codes, this product cannot be returned once sold. If you have any questions, please confirm with customer service in advance
Color: As shown
Material: PCB

Package Contents:
1 set * motor development board controller
