Summary
- 1. Working Voltage:DC12V-36V
- 2. Current:Standby less than 10mA,Working less than 128mA
- 3. Working Temperature:-10℃ - +60℃
- 4. Receiver Frequency:315MHz/433.92MHZ
- 5. Receiving Sensitivity:-105dB
12V 24V 4-Way Remote Control Point-Acting Self-Locking Interlocking Adjustable Access Gate Control Panel Description
1. Working Voltage:DC12V-36V
2. Current:Standby less than 10mA,Working less than 128mA
3. Working Temperature:-10 - +60
4. Receiver Frequency:315MHz/433.92MHZ
5. Receiving Sensitivity:-105dB
Output State:Switching Value
Max Load:10A Relay, Resistive load less than 8A,Inductive load less than 3A
Encoding Type:Learning Code
Add transmitter by the Learning Button the receiver
About Working way:
Working way changed by Learning button
Momentary:Press the Learning Button 1 times.
Relay:Press and hold ; Release Off.
Toggle:Press the Learning Button 2times.
Relay:Press ; Press same button again Off.
Latched:Press the Learning Button 3 times.
Relay:Press ; Press other button Off.
2channel Momentary+2channel Latched: Press the Learning Button 4 times.
2channel Momentary+2channel Toggle: Press the Learning Button 5 times.
2channel Toggle+2channel Latched: Press the Learning Button 6 times.
Colour:White
Material:Plastic
Size:Case Size:96x80x29mm
Package Contents:
1 * Controller
1 * Remote control (delivered without 1 x 12v23A battery)
Details
| OPC | PPD9PYH |
|---|---|
| Brand | Typecat |
| Codes | 6032489096605 (EAN) |
Product Data
| Height | 2cm |
|---|---|
| Width | 8cm |
| Length | 9cm |
| Weight | 0.131kg |
| Colour | White |
| Material | Plastic |
