15W Dual Coil Wireless Charging Module Charger PCBA Multi-Purpose Home Car Device Motherboard

15W Dual Coil Wireless Charging Module Charger PCBA Multi-Purpose Home Car Device Motherboard Description

1. Support up to 15W wireless charging power, fast charging speed and high efficiency 2. Through different input voltages, it supports charging modes such as 5W, 7.5W, 10W and 15W, which is suitable for all kinds of smartphones and tablet devices. 3. The product has multiple protection functions such as over-current, over-voltage, over-temperature, short circuit, etc., which makes it and more secure to use. 4. High-quality coil materials are used to efficient energy transfer and reduce energy loss. 5. PCBA boards undergo quality control to long-term stable operation and prolong service life. Compliant with WPC V1.2.3 wireless charging specification Product standard: Supports for fast charging protocol, compatible with for /8/8p/12/13 charging protocols Built-in MCU, 12 bits high-precision ADC, communication decoder. Input voltage/current: 5V-2A, 9V-1.67A, 12V-1.5 Output Current: 5V-1A,9V-1.1 9V-1.66 Support up to 15W power output Efficiency up to 75%-85 Sensing distance less than equal 8mm Operating frequency:100-200Khz Support dynamic energy balance Intelligent identification,15W charging With over-current, over-voltage, over-temperature, short-circuit and other fourfold protection function Support foreign object detection (FOD) Main board size: 48mmx33mmx2.7mm Coil size: 82mmx46mm (OD) Color:As Shown Material:PCB Package Contents: 1 * Wireless Charger Module Only the above package content, other products are not included. Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
