2.9 Inch Display Local Refresh 296X128 Resolution SPI Communication Interface ，Compatible with for Raspberry Pi 4 /Arduino

2.9 Inch Display Local Refresh 296X128 Resolution SPI Communication Interface ，Compatible with for Raspberry Pi 4 /Arduino Description

No backlight, power can be a long time to maintain the display of the last screen

Very low power consumption, basically only on refresh

SPI control interface, can access for Raspberry Pi\/Jetson Nano\/Arduino\/STM32 and other main control board

Onboard level conversion chip, compatible with 3.3V and 5V microcontroller interface

Provide complete information manual (for Raspberry Pi\/Jetson Nano\/Arduino\/STM32 and other sample programs)

Specification

Working voltage: 3.3V\/5V

Communication interface: 3-wire SPI, 4-wire SPI

Dimensions: 89.5x 38mm

Display size: 66.89 x 29.05mm

Resolution: 296 * 128pixels

Display color: black and white

Gray level: 2

Partial refresh: 0.3S

Refresh power consumption: 26.4mW(typ.)

Sleep current: Less than 0.01uA (close to 0)

Viewing angle: Greater than 170\u00B0

color: blue

Material: Plastic+Metal

Package Contents:

1 * Display

1 * 20cm Connection Cable
