35M-4.4GHz ADF4351 Development Board PLL Signal So

35M-4.4GHz ADF4351 Development Board PLL Signal So Description

Features: New and high quality
Made of high-quality materials,
35M-4.4GHz PLL Signal Source Synthesizer ADF4351 Development Board
Control mode: Three-wire SPI control pin and le ad lock pin can achieve all state functions, including point scanning and frequency hopping. is 1K, and the low-frequency step can be 0.1K, which is determined by the crystal frequency.

Specifications:
Frequency range: ADF4351: 35M-4.4G,
Power supply: DC002 interface DC4-9V typical value 5V
OUTPUT SIGNAL: 2.2-4.4G BASE (SINE WAVE)
Output signal interface: SMA female
Default +-50ppm 25M activated crystal
Connector diameter: 6.5 mm (.)
Material: PC+Metal
colour: Black

Package Contents:
1 x Development Board(Due to different product batches, the appearance may be different, which does not affect use.)

Only the above package content, other products are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
