65-120Kpa DC12V 6W Mini Vacuum Pump Negative Press

65-120Kpa DC12V 6W Mini Vacuum Pump Negative Press Description

Micro-pump is powered miniature DC motor drive, drive internal mechanical eccentric eccentric motion, driven by an eccentric movement inside the diaphragm reciprocates.
Whereby the pump chamber fixed volume of air compression (compression suction port is closed, the exhaust port is formed to open slightly positive pressure), stretching (compressed exhaust port is closed, a negative pressure sucking mouth open), the pumping air intakes with the outside atmospheric pressure difference, at a pressure difference, the gas pressure (suction) into the pump chamber, and discharged from the exhaust port.
Micro-pump is mainly used for medicine, gas analysis sampling, instrumentation and other fields. Completely maintenance-free, and no oil pump, do not pollute the transmission medium.
Small, stable and reliable, hand-held instrument for pump-priming, low noise, low power consumption. Especially -suitable for high negative environmental requirements.

type:DC12V Mini Vacuum Pump
Operating voltage: DC9V ~ 14V
Rated voltage: DC 12V
Current Rating: 500mA
Power Rating: 6W
Suction capacity: 5L / min
Vacuum degree: 65kpa
Maximum pressure: 120kpa
Noise: Less than 60db
Suitable for 4.5-6mm tube. Mainly about the hardness. The largest part of the outer diameter is 6.5mm.
Colour:silver + black
Material:Metal + Plastic

Package Contents:
1 x Vacuum suction pump

Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
