Raymarine E70061?i60 Wind Instrument Display?Analogue & Digital?For Sa

Raymarine E70061?i60 Wind Instrument Display?Analogue & Digital?For Sa Description

Raymarine i60 Instrument Displays Stylish displays for sailboaters!

The new i60 instruments are designed to complement the all new Raymarine cSeries and eSeries multifunctional displays. Designed specifically for sailboaters, these stylish, dedicated-function instruments cover wind and close-hauled wind options in analogue and digital formats.

Excellent viewing angles for both day and night conditions and simple, push-button controls make i60 instruments extremely easy to see and use. They are also simple to install thanks to the front-mount design.

Features

• Large analogue dials
• Red backlighting for improved visibility
• SeaTalk and SeaTalkng interfaces
• NMEA2000 (compatible) interface
• Built-in transducer interface
• 110mm x 115mm footprint identical to older Raymarine ST60+ instrumentation
• Large controls for ease of use at sea
• Low power consumption
• Multiple data source support eliminates potential data conflicts
• Front mounted design for simple installation

Raymarine i60 Instrument Displays   Raymarine i60 Wind Instrument Display

• Analogue and digital data
• Calculates apparent (relative) and true wind speed/angle (true wind requires SeaTalk speed through water data)

  Raymarine i60 Close Hauled Wind Instrument Display

• Magnified 20° - 60° display
• The perfect instrument when a single degree can make all the difference

Models:

i60 Wind

i60 Close Haul Wind

E70061

E70062

Nominal Voltage 12V DC Operating Voltage

Range 10 - 16V DC Power Consumption typically <1W (display only) and 2.4W maximum with transducer connected Current Consumption 45 to 65mA (display only) and 200mA maximum with transducer connected Operating Temperature Range -20°C to +55°C Storage Temperature -30°C to +70°C Relative Humidity up to 93% Waterproofing Standard IPX6 Connections 2 x SeaTalkng and transducers Conformance Europe 2004/108/EC
