STM32F407VET6 Development Board - STM32 Minimum System Learning ARM Core +3.2 Inch LCD TFT Screen

STM32F407VET6 Development Board - STM32 Minimum System Learning ARM Core +3.2 Inch LCD TFT Screen Description

Onboard:SD card slot. RTC Battery:CR1220. Wireless Communication:NRF2401 Interface. Data storage:W25Q16. Support FMSC LCD Interface. Multi-user keys. All the CPU-10 lead. 2.54mm integer multiples spacing pin. STM32F407VET6:the high performance STM32 MCU which. Core: - 32-bit RISC. Feature:a full set of single-cycle instructions. Operating Frequency: 168MHz, 210 DMIPS/1.25 DMIPS/MHz. Operating Voltage: 1.8V-3.6V. Package: LQFP100. Storage Resources: 512kB Flash, 192+4kB
Resource: 3 x SPI, 3 x USART, 2 x UART, 2 x I2S, 3 x ; 1 x FSMC, 1 x SDIO, 2 x CAN; 1 x USB 2.0 /HS Controler(with DMA); 1 x USB HS ULPI; (used for external USB HS PHY)1 x 10/100 Ethernet ; 1 x 8 to 12-bit parallel camera interface; 3 x AD(12 bit,1us), 2 x DA(12 bit)
Display type:TFT 3.2. Driver IC:ILI9341. Operating Temp.:-20-70. Storage Tem.:-30-80. General Tolerance: plusmn0.2. Display resolution: [240xRGB](H) x 320(V)
Output: 720 source outputs, 320 gate outputs. Common electrode output (). a-TFT LCD driver with on-chip full display RAM: 172,800 bytes.
Due to different product batches, the appearance , which does not affect the use.

System Interface:
8-bits, 9-bits, 16-bits, 18-bits interface with 8080-I/8080-1I series MCU
6-bits, 16-bits, 18-bits RGB interface with graphic controller
3-line/4-line serial interface
Display mode:
Full color mode (ldle mode OFF):262K-color (selectable color depth mode by software)
Reduce color mode (Idle mode ON):8-color
Power saving mode:
Sleep mode
On chip functions:
generator and adjustment
Timing generator
Oscillator
DC/DC converter Line/frame inversion
1 preset Gamma curve with separate RGB Gamma correction
Content Adaptive Brightness Control
(3 times):
8-bits for ID1, ID2, ID3
7-bits for adjustment
Low-power consumption architecture
Low operating power supplies:
VDDI=1.65V-3.3V (logic)
VCI=2.5V-3.3V (analog)
LCD Voltage drive:
Source/ power supply voltage
AVDD-GND=4.5V-5.5V
VCL-GND=-1.5V--2.5V
Gate driver output voltage
VGH-GND=12.0V-21.0V
VGL-GND=-7.0V- -12.5V
VGH-VGL less than equal 32V
driver output voltage
VCOMH=3.0V-(AVDD ndash 0.2)v
VCOML=(VCL+0.2)V-0V
VCOMH-VCOML less than equal 6.0V
Operate temperature range:-40 to 85
a-Si TFT LCD storage capacitor: on Common structure only
Colour:As Shown
Material:PC

Package Contents:
1 * STM32F407VET6 Development Board Kit

Only the above package content, other products are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
