U100K 3.5In 1.44MB 1000 Floppy Disk Drive to USB Emulator

U100K 3.5In 1.44MB 1000 Floppy Disk Drive to USB Emulator Description

Use A Normal USB Flash Drive As The Medium For The Transfer Design.
34pin Floppy Drive Interface, 5V DC Power Supply, Easy To Install.
1000 Partitions From A USB Flash Drive Can Be Used.Built-In Self-Formatting.
Floppy Drive With 34pin Connector And 5v Dc Power Plug.Use A 2hd Floppy Disk With A Capacity Of 1.44mb.
Disk Format:Number Of Cylinders:80, Tracks:160 Sectors/Tracks

18 Bytes/Sector:512 Data
Transfer Rate:500 Kbps
Encoding Method:MFM
Control Board:
8 Segment Number:Represents The Partition Number
Green Led:Read And Write Operation Status
Usb Port:Connect A USB Flash Drive
Button:
The Left Button Is Used To Go Up Ten Digits, The Right Button Is Used To Go Up Ten Digits, And Pressing The 2 Buttons At The Same Time Is Ok
Rise To 100 Places
Format The Usb Flash Drive.
1. Format Usb Flash Drive As 1000 Partitions With The Built-In Self-Formatting Feature
2. Install The Emulator On Your Computer And Format Each Partition By Operating Driver A.
3. Using The Emulator Ufa1m44-100, Insert The Usb Flash Drive Into It,
Connect To The Computer, For Xp/2000/7, It Be Recognized As Removabe Driver A Or B, Formatting Each Partition.
The Ufa1m44-100 Also Has Built-In Self-Formatting.
Read And Write Data.
1. Install The Emulator On Your Machine
2. Install The Emulator On Your Computer
3. Connect A USB Flash Drive On Your Computer To Read And Write Data Directories Through Software, For XP/2000
4. Using The Emulator Ufa1m44-100, Insert It Into A Usb Flash Drive, Connect It To A Computer, Read And Write Data Under Xp/2000/7.
Need Attention: Are Not Supported
Colour:Black
Material:ABS

Package Contents:
1 * Host
1 * CD
2 * Jump Cap
4 * Screw

Only the above package content, other products are not included.
Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
