XY-BLDC 3-Phase DC 200W 12-30V Brushless Motor Drive Board Controller 10KHz PWM Driver Hall Module

XY-BLDC 3-Phase DC 200W 12-30V Brushless Motor Drive Board Controller 10KHz PWM Driver Hall Module Description

Specification: XY-BLDC Is A 200w Three-Phase Hall Bldc Motor Controller. Support Plc 0-5v Analog Signal Control And Pwm To 0-5v Control. 1>. Three-Phase Hall Sensor Control 2>. Drive 200w High-Power Bldc Motor 3>. Forward And Reverse Control Switch 4>.0-5v Analog Signal 1>. Product Name: Xy-Bldc Three-Phase Hall Bldc Motor Controller 2>. Model: Xy-Bldc 3>. Working Voltage: Dc 12v-30v 4>. Rated Current: 7a 5>. Current: 10a 6>. Drive Power: 200w 7>.Bldc Motor Angle: 120 Degrees (Max) 8>. Overcurrent Protection: Yes 9>. Forward And Reverse Control: Yes 10>. Brake Control: Yes 11>. Pwm Control: Yes 12>. Analog Signal Control: Yes 13>. Operating Temperature: -40-85 14>. Working Humidity: 0%995%Rh 7. Note: 1>. If The Power Exceeds 100w Or The Ambient Temperature Exceeds 100w, Additional Cooling Equipment Needs To Be Added If The Temperature Exceeds 30 C. 2>. It Is Recommended To Use A Small Power Supply, Such As A 9v 1a Power Supply, To Avoid Damage To The Module. 7>. Please Read The Manual And Instructions Carefully Before Use. Product Size: 80.00 X 30.00 X 10.00 MM/3.15 X 1.18 X 0.39 Inch Motor Type: Dc Motor Color: As shown Material: PC Package Contents: 1 * XY-BLDC Brushless Hall Motor Drive Board Only the above package content, other products are not included. Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
