For EMID & Card Dual Frequency Access Control Card Reader,Wiegand26/34,UART TTL RFID Card Reader, NFC Card Reader
Brand Brecantia
Nuovo
Disponibile
Perché amerai fare acquisti su OnBuy:
- Ottieni Cashback su ogni acquisto – spendilo subito sul tuo prossimo ordine
- Consegna gratuita – su milioni di articoli in tutto il sito
- I clienti ci amano – 132,000 recensioni con valutazione « Eccellente »
32,83 €
Consegna GRATUITA
1%
Che cos'è il Cashback istantaneo?
Scopri di più
I prezzi degli articoli in vendita su OnBuy includono l’IVA
Opzioni di pagamento a rate senza interessi disponibili
Vedi la descrizione completa e i dettagli del prodotto
Consegna: Standard (Gratis) | sab 22 - mar 25 ago
Resi: 30 giorni
Protezione dei pagamenti per 180 giorni
Descrizione e dettagli
Riepilogo
- Product Name: Dual-frequency access control reader; Operating Frequency: 125Khz , 13.56Mhz; Sensing distance: 0-15CM; Operating voltage: DC5-16V; Operating Current: Static Less than 30mA;Dynamic Less than 40mA; Communication format: Wiegand26/34, UART TTL; Working humidity: 10%~90%; Baud rate: 9600.N.8.1; Working temperature: -30℃~85℃; Ways of identifying: Swipe card
- Card reading types: IC card, supports S50, S70 and their compatible cards, M1 card, ID card, EM4100 card etc.(does not support HID, Cobra, APCiK, etc.)IC card, supports S50, S70 and their compatible cards, M1 card, ID card, EM4100 card etc.(does not support HID, Cobra, APCiK, etc.)
- Installation precautions: The line from the card reader to the controller: It is recommended to use an 8-core shielded multi-strand twisted pair network cable (two of which are spare, if the card reader light feedback legal card is not required, the LED cable can not be connected, if the buzzer of the card reader is not used) The Buzzer line can not be connected to the illegal card feedback from the device), and the data lines Data1 and Data0 are a pair of twisted pairs.
- UART TTL RFID Card Reader
- Doorbell NFC Card Reader
Descrizione di For EMID & Card Dual Frequency Access Control Card Reader,Wiegand26/34,UART TTL RFID Card Reader, NFC Card Reader
Product Name: Dual-frequency access control reader; Operating Frequency: 125Khz , 13.56Mhz; Sensing distance: 0-15CM; Operating voltage: DC5-16V; Operating Current: Static Less than 30mA;Dynamic Less than 40mA; Communication format: Wiegand26/34, UART TTL; Working humidity: 10%~90%; Baud rate: 9600.N.8.1; Working temperature: -30~85; Ways of identifying: Swipe card
Card reading types: IC card, supports S50, S70 and their compatible cards, M1 card, ID card, EM4100 card etc.(does not support HID, , APCiK, etc.)IC card, supports S50, S70 and their compatible cards, M1 card, ID card, EM4100 card etc.(does not support HID, , APCiK, etc.)
Installation precautions: The from the card reader to the controller: It is recommended to use an 8-core shielded multi-strand twisted pair network cable (two of which are spare, if the card reader light feedback legal card is not required, the LED cable can not be connected, if the buzzer of the card reader is not used) The Buzzer can not be connected to the illegal card feedback from the device), and the data lines Data1 and Data0 are a pair of twisted pairs.
The wire diameter is recommended to be more than 0.3 square millimeters. The longest can not exceed 100 meters. The shield wire is connected to the GND of the controller.
The card reader is installed a metal surface. Since the card reader is a radio frequency product, the metal pair near the front or the rear will absorb its radio frequency signal. If the metal surface is large, it will even affect the card reader. card, or the reading distance is very attenuated.
The distance between the two card readers will also affect the card reader, some will shorten the card reading distance, and some will cause the two card readers to read the card at the same or the card reader cannot read the card.
Solution: Try not to insta
Dettagli
| OPC | PX62CGQ |
|---|---|
| Marchio | Brecantia |
| Codici | 4712554865146 (EAN) |
| Informazioni sul prodotto e sulla sicurezza |
Dati prodotto
| Height | 2cm |
|---|---|
| Width | 5cm |
| Length | 5cm |
| Weight | 0.0225kg |
| Colour | As Shown |
| Material | Plastic |
