Faces Bottom3 Functional Panel Expansion Base Faces 3 Bottom Board Faces Bottom V3.0 for Faces Series
În stoc
De ce îți va plăcea să cumperi de la OnBuy:
- Câștigi Cashback la fiecare achiziție – folosește-l la următoarea comandă
- Livrare gratuită – la milioane de produse de pe site
- Clienții ne iubesc – 135,000 de recenzii cu evaluare “Excelent”
Prețurile articolelor vândute de OnBuy includ TVA.
Opțiuni de plată în rate fără dobândă disponibile
Vezi descrierea completă și detaliile produsului
Livrare: Standard (Gratuit) | vin 2 - mie 7 oct.
Vândut de: JJBRDZ
Returnări: 30 zile
Protecție la plată pentru 180 de zile
Te-ar putea interesa și
Rezumat
- Faces Bottom3 is a functional panel expansion base for the Faces series, connecting to the host via the M5-Bus. The base provides a 2.54-22P input panel bus, which can be used to connect function panels such as keyboards, calculators, and game controllers.
- It features a built-in 600mAh rechargeable battery and a TP4057 charging IC, supporting offline power supply and stable charging. RGB light strips are integrated on both sides (10 RGB LEDs in total), and the top provides 2 x HY2.0-4P expansion ports (PORT.B / PORT.C), along with RGB LED IO signal switching support.
- The back is equipped with Pogo Pin magnetic charging contacts, M3 screw holes, and wall-mount fixing holes for easy installation and mounting; the bottom features a lanyard hole for convenient carrying.
- Functional Panel Expansion Base
- Faces Bottom v3.0
Descriere Faces Bottom3 Functional Panel Expansion Base Faces 3 Bottom Board Faces Bottom V3.0 for Faces Series
Faces Bottom3 is a functional panel expansion base for the Faces series, connecting to the host via the M5-Bus. The base provides a 2.54-22P input panel bus, which can be used to connect function panels such as keyboards, calculators, and game controllers.
It features a built-in 600mAh rechargeable battery and a TP4057 charging IC, supporting offline power supply and stable charging. RGB light strips are integrated both sides (10 RGB LEDs in total), and the top provides 2 x HY2.0-4P expansion (PORT.B / PORT.C), along with RGB LED IO signal switching support.
The back is equipped with Pogo Pin magnetic charging contacts, M3 screw holes, and wall-mount fixing holes for easy installation and mounting; the bottom features a lanyard hole for convenient carrying.
Features
Compatible with Faces series function panels (Gen 1 / Gen 3)
Compatible with Core series main controllers (Core1 / Core2 / CoreS3, etc.)
RGB LED strips both sides (5 LEDs per side)
2 x HY2.0-4P expansion (PORT.B / PORT.C)
Built-in 600mAh rechargeable battery
Integrated TP4057 charging IC
Pogo Pin magnetic charging contacts the back
LED IO switching , compatible with different hosts
Battery power the back
M3 screw holes and wall-mount fixing holes the back; lanyard hole at the bottom for convenient carrying
Specifications
Host Bus Interface: M5-Bus 2x 2.54-30P
Input Panel Bus Interface: 2.54-22P
Expansion : 2 x HY2.0-4P (PORT.B / PORT.C)
Battery: 600mAh
Charging IC: TP4057
Input Power: 5V
RGB LED: 10 x SK6812 (5 LEDs per side)
Charging Method: Pogo Pin magnetic charging the back
Mounting Method: M3 screw holes / wall-mount fixing holes
Power Consumption:
Power- unconfigured state: [email protected]
RGB LED white light at max b
Detalii
| OPC | PYF6CPN |
|---|---|
| Brand | Torribaly |
| Coduri | 4713752567306 (EAN) |
| Informații despre produs și siguranță |
Date despre produs
| Height | 2cm |
|---|---|
| Width | 5cm |
| Length | 10cm |
| Weight | 0.105kg |
| Colour | Gray & Black |
| Material | PCB+Plastic |
