KWS-AC2503WF AC 85-290V Wattmeter Power Meter Voltmeter Ammeter Module Support WI-FI Function, 0-500A

Descriere KWS-AC2503WF AC 85-290V Wattmeter Power Meter Voltmeter Ammeter Module Support WI-FI Function, 0-500A

1. Equipped with a professional metering chip, the device independently performs intelligent data processing, making it easy to use and enabling quick and convenient testing.
2. Six alert functions: Overvoltage, undervoltage, overcurrent, overpower, and overtemperature alert, with real- alerts for fault conditions.
3. Eight measurement parameters displayed simultaneously the full screen: Voltage, current, power, , temperature, frequency, timer, and power factor are shown at the same .
4. Snap-fit structure for secure installation: Made from flame-retardant PC material with an omnidirectional snap-fit design, ensuring a secure and reliable installation; the flame-retardant feature enhances safety.
5. Wide range of applications: Suitable for residential, commercial, industrial, and outdoor remote power monitoring scenarios, enabling real- monitoring and intelligent management of power data.

Parameter:
Voltage Range: AC 85-290 V
Current Range: 0-500 A
Power Range: 0-145 kW
Counting Range: 0-999 hours
consumption range: 0-99,999 kWh
Temperature range: -50 to 150C
Frequency range: 50-60 Hz
Power factor: 0.00-1.00 PF
Display dimensions: 108 x 65 mm
Cutout dimensions: 144.2 x 89.2 mm
The factory default settings are as follows:
Overvoltage alert: 275.0 V
Undervoltage alert: 85.0 V
Overcurrent alert: 0 A
Overpower alert: 0 kW
Over- alert: 00000 kWh
Timer alert: 000:00 T
Over-temperature shutdown setting: 150 C
Timer: 000:00 T
consumption: 00000 kWh
Color: Black
Material: PC
Specification: 500A

Package Contents:
Multi function table * 1
Current Transformer* 1
NTC sensing cable * 1
