LoRa Wireless Transmission Module SX1276 RF Module LoRa1276-C1100mW 20dBm 915MHz

Descriere LoRa Wireless Transmission Module SX1276 RF Module LoRa1276-C1100mW 20dBm 915MHz

1. Frequency Range: 915 MHz
2. Sensitivity: -139 dBm @ LoRa
3. Maximum Output Power: 20 dBm
4. Low Receive Current: 10.8 mA
5. Sleep Current Less than 1.5 μA

Data Rate: 1.2-300 Kbps @FSK, 0.018-37.5 Kbps @ LoRa
LoRa, (G)FSK Modulation Modes
Built-in Antenna ESD Protection
127 dB Dynamic Range RSSI
256-Byte FiFo with CRC Frequency Hopping
Built-in Temperature Sensor
Unobstructed Signal
Operating Temperature Range: -40C to +85C
Applications
1. Remote Meter Reading
2. Industrial Control
3. Home Automation Telemetry
4. Toy Control
5. Sensor Networks
6. Tire Pressure Monitoring
7. Health Monitoring
8. Wireless PC Peripherals
LoRa1276-C1 The LoRa module uses the for Semtech SX1276 device, which utilizes LoRa's spread-spectrum frequency-hopping modulation technology. Its communication range and receive sensitivity far exceed those of existing FSK and GFSK modulations. It also allows multiple transmitted signals to occupy the same channel without being affected, and exhibits exceptional interference resistance. The module's antenna is integrated within the chip. Its compact size and 100mW output power make it widely applicable in industries such as wireless meter reading and remote industrial control.
The LoRa1276-C1 series modules are manufactured and tested using a strict lead-free process and comply with ROHS and Reach standards.
Color: As Shown
Material: plastic

Package Contents:
1 * LoRa Module
