4X 300W 20A - Adjustable Step Down Buck Converter Module Constant Current Voltage Regulator Power Supply Driver
Nové
Na sklade
Prečo si zamilujete nakupovanie na OnBuy:
- Získajte cashback pri každom nákupe – použite ho okamžite na ďalšiu objednávku
- Doprava zadarmo – na milióny produktov na celej stránke
- Zákazníci nás milujú – 127,000 hodnotení s “Vynikajúcim” hodnotením
20,98 €
25,18 €
17 % zľava!
+3,01 € doručenie
1%
Čo je okamžitý Cashback?
Zistiť viac
Ceny produktov predávaných spoločnosťou OnBuy sú uvedené s DPH.
K dispozícii sú aj bezúročné možnosti platby
Zobraziť celý popis a podrobnosti o produkte
Doručenie: Štandard (3,01 €) | sob 11 - pia 17 júl
Predáva: CollBea
Vrátenie tovaru: 30 dní
180-dňová ochrana platieb
Najobľúbenejšie v Olejové čerpadlá do automobilov
Popis a podrobnosti
Zhrnutie
- With a wide input voltage range from 6V to 40V, the step-down converter can accurately adjust output voltage and current.
- The efficiency can be up to 96%, measured at 20A, converting 24V to 12V.
- It is designed with 75V/80A large current dual MOS tube.
- Input and output use high frequency low resistance electrolytic capacitor, low ripple, stable output.
- Wiring is convenient with these large current 30A screw terminals.
4X 300W 20A - Adjustable Step Down Buck Converter Module Constant Current Voltage Regulator Power Supply Driver Popis
With a wide input voltage range from 6V to 40V, the step-down converter can accurately adjust output voltage and current.
The efficiency can be to 96%, measured at 20A, converting 24V to 12V.
It is designed with 75V/80A large current dual MOS tube.
Input and output use high frequency low resistance electrolytic capacitor, low ripple, stable output.
Wiring is convenient with these large current 30A screw terminals.
The buck module has 2 heat sink that could enhance heat dissipation.
When there is a difference between input and output voltage, please decrease power and current.
Input Voltage: 6V to 40V (10V to 40V is suggested)
Output Voltage: 1.2V to 36V
Output Current: 20A(max.), 15A(suggested)
Efficiency: 95%(24V to 12V, 20A)
Output Ripple: less than equal 50mV
Wiring Method: Terminal
Short Circuit Protection: Self-recovery (cannot short circuit for long )
Size: 60 x 53 x 27mm / 2.36 x 2.08 x 1.06inch
VO+: Output positive
VO-: Output negative
+IN: Input positive
-IN: Input negative
CV: Output voltage adjustment
CC: Output current adjustment
EN: Enable, low voltage level shut off output; suspension, high voltage level is effective
When input and output is common grounded, no-load CV output constant voltage,CC output constant current
Colour:As shown
Material:PC+Metal
Package Contents:
4 x 300W 20A Step Down Buck Converter
Podrobnosti
| OPC | PMDPYGY |
|---|---|
| Kódy | 4712500790638 (EAN) |
Údaje o produkte
| Height | 12cm |
|---|---|
| Width | 7cm |
| Length | 7cm |
| Weight | 0.266kg |
| Colour | As Shown |
| Material | PC+Metal |
