5X ESP32-S3 3.5 Inch Capacitive Touch Display IPS TFT 8M PSRAM 16M FLASH 320x480 ESP32 WiFi BT Module for

5X ESP32-S3 3.5 Inch Capacitive Touch Display IPS TFT 8M PSRAM 16M FLASH 320x480 ESP32 WiFi BT Module for Popis

3.5-inch color screen, support 16 BIT RGB 65K color display, display rich colors
320X480 resolution
The sample program has been programmed in the factory and can be plugged in
With TF card slot for easy expansion storage
Provide for library functions and sample programs to facilitate rapid secondary development

Lithium battery charging and discharging circuit with overcharging and discharging protection
to 12 IOs can be used separately by customers
Support one-click download program
Military-grade process standards, long-term stable work
SKU: Capacitive touch:JC3248W535C_I_Y
Size: 3.5 inch
Type: TFT
Driver chip: AXS15231B
Resolution: 320 x 480(Pixel)
Effective display area: 73.4x 49.0mm
Module size: 94.5x62.0mm
View: IPS
Operating temperature: -20-70
storage temperature: -30-80
Operating Voltage: 5V
Power consumption: About 150mA
Colour:black
Material:PCB+Plastic
Due to different batches, there may be differences in product appearance and printed text, which will not affect use

Package Contents:
5 x ESP32-S3 3.5-inch capacitive touch IPS module
