Reolink E Series E540 - IP camera, black

Reolink E Series E540 - IP camera, black Beschreibung

Description Packaging content Packaging content 1* E Series E540-B 1* Security Bracket 1* Strap 1* Power Adapter 1* Reset Needle 1* Pack of Screws 1* 4.5m Power Extension Cable 1* 1m Network Cable 1* Mounting Template 1* Quick Start Guide 1* Surveillance Sticker Number of cameras 1 Mounting kit Yes Screws included Yes Manual Yes Performance Type IP security camera Placement supported Indoor & outdoor Connectivity technology Wired & Wireless Infrared (IR) cut-off filter Yes Design Form factor Spherical Mounting type Ceiling Product colour Black International Protection (IP) code IP65 Camera Lens viewing angle, horizontal 48 - 90 Lens viewing angle, vertical 37 - 68 Tilt angle range 0 - 50 Pan range 0 - 355 Image sensor Number of sensors 1 Optical sensor size 25.4 / 2.7 mm (1 / 2.7") Sensor type CMOS Lens system Number of lenses 1 Focal length range 2.8 - 8 mm Maximum aperture number 1.6 Night vision Night vision Yes Night vision distance 12 m LED type IR/White Number of illumination LEDs 12 Infra-red wavelength 850 nm Video Maximum resolution 2560 x 1920 pixels Total megapixels 5 MP Video formats supported H.264 Video compression formats H.264 Supported graphics resolutions 2560 x 1920 Video recording Yes Frame rate 20 fps Video streaming Yes Bit rate 64 Kbps - 5120 Kbps Audio Built-in speaker(s) Yes Audio system 2-way Built-in microphone Yes Network Ethernet LAN Yes Ethernet interface type Fast Ethernet Networking standards IEEE 802.11aIEEE 802.11bIEEE 802.11gIEEE 802.11nExpandFold Supported network protocols HTTPS, SSL, TCP/IP, UDP, IPv4, UPnP, RTSP, RTMP, ONVIF, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P Wi-Fi Yes Wi-Fi standards 802.11a802.11b802.11gWi-Fi 4 (802.11n)ExpandFold Bluetooth No Number of users 20 user(s) Live view Yes Storage Built-in HDD No Card reader integrated Yes Compatible memory cards MicroSD (TransFlash) Maximum memory card size 256 GB Ports & interfaces Ethernet LAN (RJ-45) ports 1 DC-in jack Yes Security Video motion detection Yes Security algorithms WPAWPA2 Human and vehicle targets classification Yes Management features Reset button Yes Power Power source type DC Power consumption (max) 12 W DC output voltage 12 DC output current 1 A Operational conditions Operating temperature (T-T) -10 - 50 C System requirements Windows operating systems supported Yes Mac operating systems supported Yes Mobile operating systems supported AndroidiOS Weight & dimensions Height 120 mm Diameter 9 cm Weight 415 g Despite our best efforts we cannot guarantee that the published specifications and images do not contain errors or mistakes that cannot however constitute the basis for claims.
