TXB0104 Bidirectional Level Shifter Module Auto-Direction ,Automatic Bidirectional Voltage Conversion Module for DIY

TXB0104 Bidirectional Level Shifter Module Auto-Direction ,Automatic Bidirectional Voltage Conversion Module for DIY Popis

Adopts TXB0104 chip for automatic bidirectional level shifting, no direction pin configuration required, easy wiring & great compatibility
Signal transmission free from resistor voltage divider interference, high-speed signals maintain integrity to lower debugging failures
Supports pull- resistors above 50KΩ, compatible with most common control circuits
Peripheral components pre-soldered to shorten development cycles
compact size, ideal for project development, electronic DIY circuit design & debugging

Overview;
Traditional mainboards work 5V logic voltage, while most modern sensors, displays, flash memory modules only run 3.3V. Mismatched voltage levels often burn components, distort signals and cause abnormal data, bringing troubles to electronic DIY and circuit development.
Classic solutions like resistor voltage division and 74LVX245 unidirectional level shifters have obvious drawbacks: resistor dividers severely disrupt high-speed signals and cause severe signal attenuation leading to hard-to-locate circuit faults; unidirectional conversion chips need complex wiring and cannot work with bidirectional interfaces, resulting in poor versatility.
Specifications
Model: TXB0104 Bidirectional Level Shifter Module
Conversion Mode: Fully automatic bidirectional voltage conversion between arbitrary voltages
Applicable Voltage: 5V 3.3V, matches most mainstream MCUs and modules
Built-in Components: Dual-side 0.1uF filter capacitors, 10K pull- resistor for output enable
Supported Pull- Resistance: 50KΩ
Core Advantages: No soldering needed, plug-and-, no direction setup, stable high-speed signal
Application Scenarios: Project development, electronic DIY circuit design, IoT module debugging
Color: Black
Material: plastic

Package Contents:
1*TXB0104
