FOC Brushless Motor Driver Board BLDC Current Voltage Isolation Acquisition STM32F103VET6

FOC Brushless Motor Driver Board BLDC Current Voltage Isolation Acquisition STM32F103VET6 Beskrivelse

Adopt STM32F103VET6 as the main control MCU
Use PWM signal isolation drive, logic chip with short circuit protection for upper and lower tubes
3-way discrete high and low side gate driver IR2110 and 6 NMOS tubes form BLDC drive circuit, with Hall encoder isolation circuit and hardware overcurrent protection circuit with rapid response
Can be used to control the smooth and high-precision operation of Hall sensor BLDC brushless motor within 3000RPM 10A
Reserve bus voltage isolation detection, NTC thermal protection detection, three-phase back electromotive force isolation detection, three-phase current isolation detection circuit to facilitate secondary development

Adopts STM32F103VET6 Arm 32-bit Cortex-M3 CPU
Adopts 3-way IR2110STRPBF gate driver, PWM isolation circuit, short-circuit prevention logic circuit, and 6 NMOS tubes to form the BLDC drive part
Supports 3000RPM brushless motor with Hall encoder by default
Supports maximum load current by default: 10A, exceeding 10A will automatically trigger hardware short-circuit protection
Power supply voltage: DC12-40V;
Onboard 5V and 3.3V isolated power output
Colour:Black
Material:PCB

Package Contents:
1 x Brushless Motor Control Driver Board
