M5Stack Byte Button Unit with 8-Way Tactile Input Unit STM32 RGB Light for IoT Home Control

M5Stack Byte Button Unit with 8-Way Tactile Input Unit STM32 RGB Light for IoT Home Control Beskrivelse

Enhance your IoT and home projects with the M5Stack Byte button unit. This compact module features 8-way tactile inputs, perfect for user interfaces and control settings
Using STM32 as the master, it supports I2C communication, has two Port A I2C interfaces board, and supports multiple Unit ByteSwitch units cascaded to meet the needs of complex systems
The unit also includes integrated RGB lighting, adding a visual dimension to your project, which can indicate status, alarms, or just increase aesthetics
It can realize toggle input detection and dynamic lighting status feedback, suitable for home control, game entertainment equipment, education development platform, industrial status display, and interactive exhibitions
Its versatility makes it suitable for a wide range of applications in home systems, educational purposes, and DIY electronic products

MCU: STM32G031G8U6, 32-bit ARM Cortex-MO+ core, main frequency 64 MHz
Toggle : 8-way independent toggle (double-pole double-throw)
RGB lamp beads: WS2812C-2020 (9 pieces)
Communication interface: I2C communication @0x46
Grove interface: 2 (12C bus cascade expansion)
Standby power consumption: [email protected]
Operating temperature: 0-40
Material: PCB
Color: As shown
(The product appearance and printed words may vary depending the batch, but this does not affect use)

Package Contents:
1 x
1 x cable
