MACH3 USB CNC 5 Axis 100KHz 12-24V Linear Motion Control Card STB5100 Breakout Board

MACH3 USB CNC 5 Axis 100KHz 12-24V Linear Motion Control Card STB5100 Breakout Board Beskrivelse

1. Support for Windows XP, Windows 7 32/64bit, Windows8, Windows10 operating system;
2. Applicable to all versions of mach3 software;
3. Support for CNC controlled 5-Axis, can connect five stepper motor driver or servo driver;
4. The maximum output pulse frequency is 100KHz, and the pulse width can automatically change with the pulse frequency, which can be applicable to the closed-loop driver of strict requirements pulse;
5. Five optocoupler isolation input signal interfaces: limit , emergency stop , auto tool zero sensor, home , NPN sensor can be connected;

1. Inverter control signal interface (optocoupler isolation): Output 0-10V speed control signal, PWM speed control signal, spindle start control signal, used for mach3 software to control spindle's speed, start and stop;
2. Four universal output signal interfaces, the maximum output 500MA current, can drive relays, solenoid valves, used to control mist, pumps, cylinders and other equipments;
3. Support for external connect electronic hand wheel, use HDR15 interface to connect electronic hand wheel, used for manual control of machine tools;
4. Add the enable signal interface, can be used to control the driver enable signal;
5. The power of control card: voltage 12-24VDC, current more than 500MA.
Colour:
Material:pcb

Package Contents:
1 * Linear Motion Control Card
