Platforma Asus Rack (1U) AMD ExpertCenter Pro ER100

Platforma Asus Rack (1U) AMD ExpertCenter Pro ER100 Beskrivelse

Description Processor Processor socket Socket SP5 Number of processors supported 2 Compatible processor series AMD EPYC 4004AMD EPYC 4005AMD Ryzen 7000 SeriesAMD Ryzen 9000 SeriesExpandFold Memory Number of DIMM slots 4 Supported memory types DDR5 UDIMM Supported DIMM module capacities 16GB32GB48GB8GBExpandFold Maximum RDIMM memory 192 GB Supported RDIMM clock speeds 5600 Storage Number of storage drives supported 4 Hot-swap HDD bays Yes Storage drive sizes supported 2.5 Supported storage drive types HDD & SSD Number of 2.5" bays 4 Graphics On-board graphics card model Aspeed AST2600 Network Ethernet LAN Yes Ethernet LAN data rates 101001000 Mbit/s2500 Mbit/sExpandFold Ports & interfaces Ethernet LAN (RJ-45) ports 3 USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 2 USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity 1 VGA (D-Sub) ports quantity 1 COM ports quantity 1 Expansion slots PCI Express slots version 5.0 PCI Express x16 (Gen 5.x) slots 1 Features Integrated BMC with IPMI Yes Trusted Platform Module (TPM) Yes Trusted Platform Module (TPM) version 2.0 Design Chassis type Rack (1U) LED indicators Yes Number of fans 8 fan(s) Certification BSMI, CE, CB, RCM, FCC(Class A), ISED Power Power supply 500 W Number of main power supplies 1 AC input voltage 100 - 240 V AC input frequency 50/60 Hz Input current 4 - 8 A 80 PLUS certification 80 PLUS Gold Operational conditions Operating temperature (T-T) 10 - 35 C Storage relative humidity (H-H) 20 - 90% Weight & dimensions Width 438.5 mm Depth 409 mm Height 43.2 mm Weight 9.62 kg Packaging data Package weight 12.4 kg Despite our best efforts we cannot guarantee that the published specifications and images do not contain errors or mistakes that cannot however constitute the basis for claims.
