TP-Link 9-Port 10/100Mbps Desktop Switch with 8-Port PoE+

TP-Link 9-Port 10/100Mbps Desktop Switch with 8-Port PoE+ Beskrivelse

Description Management features Switch type Unmanaged Ports & interfaces Basic switching RJ-45 Ethernet ports quantity 9 Basic switching RJ-45 Ethernet ports type Fast Ethernet (10/100) Fast Ethernet (copper) ports quantity 9 Power connector DC-in jack Network Networking standards IEEE 802.3afIEEE 802.3atIEEE 802.3iIEEE 802.3uIEEE 802.3xExpandFold 10G support No Copper ethernet cabling technology 100BASE-TX10BASE-T Cable types supported Cat3Cat4Cat5Cat5eExpandFold Full duplex Yes Half duplex Yes Flow control support Yes Auto MDI/MDI-X Yes Auto-negotiation Yes MAC address auto-learning supported Yes MAC address auto-aging supported Yes Data transmission Switching capacity 1.6 Gbit/s Forwarding rate 1.3392 Mpps MAC address table 2000 entries Store-and-forward Yes Design Rack mounting No Stackable No Product colour Black Housing material Metal LED indicators ActivityLinkPoEPowerExpandFold Wall mountable Yes Performance Fanless Yes Power Power source DC/PoE Power supply included No AC input voltage 220 V AC input frequency 50 Hz DC input voltage 53.5 V Input current 1.31 A Power consumption (max) 77.08 W Power over Ethernet (PoE) Power over Ethernet (PoE) Yes Power over Ethernet plus (PoE+) ports quantity 8 Power over Ethernet (PoE) power per port 30 W Total Power over Ethernet (PoE) budget 65 W Operational conditions Operating temperature (T-T) 0 - 40 C Storage temperature (T-T) -40 - 70 C Operating relative humidity (H-H) 10 - 90% Storage relative humidity (H-H) 5 - 90% Heat dissipation 262.84 BTU/h Weight & dimensions Width 171 mm Depth 98 mm Height 27 mm Packaging content User guide Yes Packaging data AC adapter included Yes Package width 223 mm Sustainability Sustainability compliance Yes Certificates Certification FCC, CE, RoHS Despite our best efforts we cannot guarantee that the published specifications and images do not contain errors or mistakes that cannot however constitute the basis for claims.
