TV-TX200 VHF/UHF Analog TV Transmitter Support HD/AV Input Analog Signal Transmitter with GP Antenna EU Plug

TV-TX200 VHF/UHF Analog TV Transmitter Support HD/AV Input Analog Signal Transmitter with GP Antenna EU Plug Beskrivelse

TV200 analog TV transmitter is a household analog TV transmitter with adjustable power and frequency
The transmission power is adjustable from 0.5W to 2W, and it can output HD high-definition 1080 signals or input CVBS analog signals
The maximum distance can reach several hundred meters without obstacles and with the transmission antenna matching the transmission frequency
Support VHF 85.25MHZ-216.25MHz setting
Support UHF 471.25MHZ-839.25MHz setting Sound frequency setting of 4.5MHZ-6.5MHZ

FM transmission frequency:
Firstly, set the transmitter to 85.25MHz VHF, with a sound frequency of 6.5MHz. The TV frequency the sound frequency will result in Equivalent to the receiving frequency of the radio,
85.25+6.5=91.75
85.25+6.0=91.25
85.25+5.5=90.75
85.25+4.5=89.75
(The product printed words may vary depending the batch, but this does not affect use)
Plug Type:EU Plug,it applies to Indonesia, Germany, France, Spain, Italy and so
Voltage:AC100-240V
Color:As Shown
Material:Aluminum Alloy

Package Contents:
1 * analog video TV transmitter with antenna
1 * adapter
