1PCS AM32 32-Bit ESC 2-4S 40A Speed Controller for RC Crawler Drone Brushless Motors

1PCS AM32 32-Bit ESC 2-4S 40A Speed Controller for RC Crawler Drone Brushless Motors Kuvaus

A new 32-bit ESC product, with a super size, very suitable for compact installation, it is a driving tool for various small model airplane brushless motors.
Selected low-power MOS tube with layout placed the same side for convenient heat dissipation and strong power.
size and high power, it is the preferred power for small aircraft, crawler, climbing vehicles.
Integrates the BEC module (5V2A), adds overcurrent copper bars, adds thermal conductive silicone sheets, and takes all performance to a higher level.
Supports mainstream control signals such as DSHOT and PWM, with linear at low speeds, violent at high speeds, and smooth speed regulation. It uses AM32 open-source firmware, which can be freely adjusted. It supports bidirectional operation, adjustable drag braking, sine start, and other functions, and fast forward and reverse switching is very smooth.

With a 470uF 35V capacitor to improve its working condition.
Item name: 32-bit ESC
Firmware: AM32
Master control: AT32
Working voltage: 2-4S Lipo
Max current: 40A
BEC: 5V2A
Support signal: PWM/DSHOT/Sine, etc.
Board size: 32x13mm
Signal cable length: 106mm
Strongly recommended! When using the AM32 ESC, it is necessary to use in conjunction with a parameter adjuster.
Parameter adjuster:
Type-C port
Special for AM32 32-bit ESC
Color: As shown
Material: plastic

Package Contents:
1 x AM32 electronic speed controller
